| SIZE | : | 1,500mm TO 2,500mm |
| OPENING | : | Square or Rectangular |
| MEDIUM | : | Water & Sewage |
| STEM TYPE | : | Non-rising stem or rising stem |
| FRAME TYPE | : | Opened Frame or Closed Frame |
| WORKING PRESSURE | : | 6 MWC TO 30 MWC |
| SEALING | : | 4 sides |
| DESIGN STANDARD | : | BS 7775/ AWWA C561 |
| LEAKAGE | : | leakage rate lower than maximum allowable defined by BS 7775/AWWA C561 |
| MATERIAL | ||
| FRAME GUIDE | : | Mild steel S275JR, Stainless Steel 304/304L or 316/316L |
| GATE | : | Mild steel, Stainless Steel 304/304L or 316/316L |
| YOKE | : | Mild steel, Stainless Steel 304/304L or 316/316L |
| SPINDLE | : | Stainless Steel 304/304L or 316/316L |
| SPINDLE NUT | : | Bronze |
| GUIDE PE | : | High Molecular Weight Polyethylene (HMWPE-500) |
| LATERAL SEAL | : | EPDM |
| LATERAL RETAINER PLATE | : | Stainless Steel 304/304L or 316/316L |
| BOTTOM SEAL | : | EPDM |
| BOTTOM RETAINER PLATE | : | Stainless Steel 304/304L or 316/316L |
| FASTENERS | : | Stainless Steel 304 or 316L |
| MOUNTING TYPE | : | Wall mounted |
| Options | : | Double Spindle Type |
| Applicable | : | Water, Sewage & Irrigation Flood Control |
